Paneltronics Breaker 30 Amps A-Frame Magnetic Waterproof

Description

• Trip free (ABYC and )

Panel Seal / Waterproof "A" Frame Magnetic Circuit Breakers Branch AC or DC circuit breaker for Paneltronics electrical distribution panels Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers UL Recognized (UL 1077) for use in the ., and CSA Certified for use in Canada Trip free (ABYC and ) Manual reset (ABYC and ) Specifications Handle Color Metal with Silicon rubber seal Maximum Amperage 50 Amps Maximum Voltage /AIC 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC ) Rated Switch Cycles Rated Switch Cycles 10,000 actuations at rated current and voltage Electrical Hardware Screw 10-32 x 3/8" pan combo head (P/N 197-188) Mounting Hardware Hex nut 1/2-32 (supplied with circuit breaker) Lockwasher 1/2" internal tooth (supplied with circuit breaker) Optional Boot Black silicone rubber (P/N 048-015)
