P60M1-0-60

Description

1/4 IN Miniature Plastic Water Pressure Regulator, NPT Female, Acetal Plug, 0-60 psi_This 1/4 inch miniature water pressure regulator is compact and lightweight with a high flow capacity. It is used in general purpose and OEM applications where a small economical package is required. It is also suitable for deionized water applications. It has a balanced piston design for applications to regulate pressure in systems that require a constant downstream and accurate flow performance. It consists of a thermoplastic body construction, NPT female connections in a straight through gauge port, a rubber disc, diaphragm, and seals of FDA grade elastomers, stainless steel internal metal components. The reduced pressure range is 0 to 60 psi (0 to 4.22 bar) and the temperature range is 33 to 150 degrees F (0.5 to 66 degrees C)._All internal metal components in contact with fluid are of 300 series stainless steel_All internal rubber components such as disc, diaphragm and seals are all FDA grade elastomers_Bottom clean out plug for service_Maximum Inlet pressure is 300 psi (21 bar)_Compact design and lightweight construction_Temperature range is 33 F to 150 degrees F (0.5 C to 66 degrees C)_Corrosion resistant thermoplastic body_Specifications_Adjustable Reduced Pressure Range 0 to 60_Adjustable Reduced Pressure Range-BAR 0 to 4.22_Body Material Plastic_Brand Watts_Corrosion Resistant Coating Yes_Disc Material Buna-N_EAN 098268224382_Gauge Option No Gauge_High Pressure Reduced Pressure Range Does Not Apply To Product_High Pressure Reduced Pressure Setting Does Not Apply To Product_Inlet Connection Size 1/4 IN_Inlet Connection Type Female Threaded_Inlet Thread Type NPT_Lead Free YES_Maximum Operating Temperature-Fahrenheit 150_Maximum Working Pressure-BAR 20.70_Maximum Working Pressure-PSI 300_Minimum Temperature - Celsius 0.50_Minimum Temperature-Fahrenheit 33_Outlet Connection Size 1/4 IN_Outlet Connection Type Female Threaded_Outlet Thread Type NPT_Part Number 0354555_Series P60_Strainer No_Strainer Material Does Not Apply To Product_Thermal Expansion Bypass No_Trim Material Does Not Apply To Product_Type Kit_Valve Style Standard
